Electrical Cabinet Door Forming Machine

The electrical cabinet door panel forming machine is the core equipment of the door panel production line. It is specifically designed to form the cut-to-length door panel blanks into finished electrical cabinet door panels through multiple rolling and bending processes. The equipment integrates reinforcing rib rolling forming, four-sided edge folding, and corner forming. It uses Cr12 hardened rollers (HRC58°-62°), a PLC control system, and a variable frequency motor drive. The production speed is 0-4 pieces/minute, with a total power of 30kW. It can process sheets with a thickness of 0.5-1.5mm and a width of 100-1000mm, making it a key piece of equipment for the automated forming of electrical cabinet door panels.

I. Simultaneous Forming of Reinforcing Ribs and Edge Bending Significantly Improves Door Panel Rigidity

Large and thin door panels require reinforcing ribs to enhance bending resistance. The equipment integrally forms multiple longitudinal reinforcing ribs before the bending process, ensuring they are seamlessly integrated with the door panel body without welding, thus guaranteeing structural strength and improving aesthetics. Simultaneously, the four-sided bending and reinforcing rib formation are completed in a continuous process, resulting in a rigid, non-deformable door panel that remains flat and does not collapse during long-term use.

II. Naturally Formed Corner Edges, Eliminating the Need for Welding

Through precise angle control in the bending section, the equipment naturally forms corner edges after bending, resulting in tight joints at the corners, eliminating the need for corner welding or grinding. The finished door panel has neat corners without weld points, saving on welding materials and labor costs, and avoiding damage to the surface coating caused by post-weld grinding. This results in better overall aesthetics and corrosion resistance for the door panel.

III. Excellent Door Panel Flatness and Seamless Assembly in One Step

Utilizing a multi-point guiding and multi-pass uniform molding process, the door panel maintains a flat surface throughout the molding process. After bending, the door panel exhibits high flatness, fitting tightly with the cabinet edges. The sealing strip experiences uniform compression after installation, achieving a protection level of IP54 or higher. No additional leveling or adjustment is required during assembly.
